FANUC Series 16i /18i Additional Manual Page 39

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
39/190
2.15.4 Notes about Scaling, Coordinate System Rotation, and Programmable Mirror
• Modal
• Instruction form
• G code
•
Auxiliary function
Note
Please command the starting of AI HPCC / AI NANO HPCC (G05 P10000) in
the state of G50(Scaling cancel), G69.1(Coordinate system rotation cancel),
and G50.1(Programmable mirror image cancel).
When the AI HPCC / AI NANO HPCC is started in either of G51, G68.1 or
G51.1 mode, P/S alarm 5012 occurs.
Note
Please turn on and off scaling, the coordinate rotation, and the programmable
mirror image in the AI HPCC / AI NANO HPCC mode.
Example) G05 P10000 ;
:
G51 …… ;
:
:
G50 ;
:
G05 P0 ;
When the AI HPCC / AI NANO HPCC mode is turned off in G51, G68, and the
G51.1 mode, P/S alarm 5313 or P/S alarm 5013 occurs.
Scaling mode
A
I HPCC / AI NANO HPCC mode
Note
G code that can be commanded in G51, G68, and G51.1 mode is limited at the
following.
G01/G02/G03
G17/G18/G19 (It is not possible to instruct in the G68 mode.)
G40/G41/G42/G39
G50/G51
G50.1/G51.1
G68/G69
G90/G91
G00
Note
Please set “1” in the parameter No.8403#1(MSU) to use the auxiliary function
(M,S,B command) in G51, G68, and G51.1 mode.
Please command the auxiliary function at an identical block in the G51, G68,
and G51.1 mode. When it is not an identical block, P/S alarm 5000 occurs.
