3.16 Jerk Control
19522 Permissible acceleration change level for each axis in speed control based
on acceleration changes for jerk control
[Data type] 2 Word axis
[Unit of data]
Increment system IS-B IS-C Unit
Millimeter –machine
0.001
0.0001
2
/ smm
Inch-machine 0.0001 0.00001
2
/ sinch
Rotation axis 0.001 0.0001
2
deg/ s
[Valid data range] 0 to 99999999
Specify a permissible acceleration change level per ms for each axis in speed
control based on acceleration changes under jerk control.
For an axis for which this parameter is 0, speed control based on acceleration
changes is ineffective.
If the parameter is 0 for all axes, speed control based on acceleration changes is
not performed at all.
19523 Permissible acceleration change level for each axis in speed control based
on acceleration changes for jerk control when linear interpolation is repeated
[Data type] 2 Word axis
[Unit of data]
Increment system IS-B IS-C Unit
Millimeter –machine
0.001
0.0001
2
/ smm
Inch-machine 0.0001 0.00001
2
/ sinch
Rotation axis 0.001 0.0001
2
deg/ s
[Valid data range] 0 to 99999999
Specify a permissible acceleration change level per ms for each axis in speed
control under jerk control.
In speed control based on acceleration changes at a corner where linear
interpolation is repeated, a permissible acceleration change level in this
parameter rather than parameter No. 19522 becomes effective.
For axes for which this parameter is 0, a permissible acceleration change level
specified in parameter No. 19522 is effective.
For axes for which parameter No. 19522 is 0, speed control based on acceleration
changes is ineffective, so this parameter is meaningless.
