FANUC Series 16i /18i Additional Manual Page 180

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
180/190
5013 HPCC:CRC OFS REMAIN
AT CANCEL
· G05 P0 was commanded with in the G41/G42 mode or
the amount of the offset remained.
· G05 P0 was instructed in in G51.1 (programmable
mirror image) mode.
· G05 P0 was instructed in G43.4(tool center point
control) modes.
5115 SPL:ERROR In the NURBS interpolation,
· There is an error in the specification of the rank.
· No knot is specified.
· The knot specification has an error.
· The number of axes exceeds the limits.
· Other program errors
5116 SPL:ERROR In the NURBS interpolation,
· There is a program error in a block under look–ahead
control.
· Monotone increasing of knots is not observed.
· A mode that cannot be used together is specified.
5117 SPL:ERROR The first control point of NURBS is incorrect.
5118 SPL:ERROR After manual intervention with manual absolute mode
set to on, NURBS interpolation was restarted.
5122 ILLEGAL COMMAND IN
SPIRAL
An illegal command was specified for spiral or conical
interpolation.
· L0 was specified.
· Q0 was specified.
· Height increment or decrement 0 was specified.
· More than 3 height axes were specified.
· Height increment or decrement was specified when 2
height axis were specified.
· Conical interpolation was specified without helical
interpolation option.
· Q<0 was specified when radius difference (Re-Rs) >0.
· Q>0 was specified when radius difference (Re-Rs) <0.
· Height increment or decrement was specified without
height axis command.
5123 OVER TOLERANCE OF
END POINT
The difference between the position of the specified and
calculated end points exceeds the permissible value
(parameter No.3471).
5124 CAN NOT COMMAND
SPIRAL
Spiral interpolation or conical interpolation was specified
in the following mode.
· Scaling
· Programmable mirror image
It is in the following conditions in the cutter
compensation C mode
· start point = center
· end point = center
5196 ILLEGAL OPERATION
(HPCC)
· The control axis detaching was done in AI HPCC / AI
NANO HPCC
mode.
After the block being executed now ends, this alarm is
generated if the control axis detaching is done in AI
HPCC
/ AI NANO HPCC mode.
· Manual intervention is executed in G43.4 (tool center
point control) or or G41.5/G42.5(tool radius
compensation for 5-axis machining) or G02.4/G03.4
(three-dimensional circular interpolation) modes.
