FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
178/190
4 Signal
HPCC mode signal
MHPCC (F066#6)
[Classification] Output signal
[Function] Indicates that the system is set to AI HPCC / AI NANO HPCC mode.
[Output condition] The signal is set to 1 if G05 P10000 (AI HPCC / AI NANO HPCC mode ON) is
specified in a program. The signal is set to 0 if G05 P0 is specified in a program or
if AI HPCC / AI NANO HPCC mode is canceled by a reset.
HPCC operation signal
EXHPCC (F066#7)
[Classification] Output signal
[Function] Indicates that the system is operating in AI HPCC / AI NANO HPCC mode (AI
HPCC / AI NANO HPCC operation is in progress).
[Output condition] The signal is set to 1 if G05 P10000 (AI HPCC / AI NANO HPCC mode ON) is
specified in a program and if specifiable data of except auxiliary function is
executed.
The signal is set to 0 when:
(1) Automatic operation is halted.
(2) Automatic operation is stopped.
(3) AI HPCC / AI NANO HPCC mode is canceled.
(4) While executing the block with auxiliary function (M code, S code, or second
auxiliary function).
(5) While executing the block with subprogram call.
(6) When either address U, V, W, or H is specified in G code system B or C.
(7) When the axis which AI HPCC / AI NANO HPCC is not effective(*1) is
instructed.
When this signal is "0", the blinking display of "AI HPCC / NANO HP" under the
right of the screen is not done.
(*1) Please refer to description of parameter No.7510 (section 3.2).
Siganl addresses
#7 #6 #5 #4 #3 #2 #1 #0
F066 EXHPCC MHPCC
