FANUC Series 16i /18i Additional Manual Page 146

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
146/190
3.9 Tool Center Point Control for 5-axis Machining
#7 #6 #5 #4 #3 #2 #1 #0
19501 FRP
[Data type] Bit
FRP A type of acceleration/deceleration of rapid traverse in AI HPCC / AI NANO
HPCC mode is :
0: Acceleration/deceleration after interpolation.
1: Acceleration/deceleration before interpolation.
Please set ‘1’ in this parameter to use Tool Center Point Control for 5-axis
Machining
19680 Type of machine configuration
[Data type] Byte
[Valid data range] 0 to 21
Set a type of machine configuration.
PRM19680 Controlled rotary axis Master and slave
0 Without rotary axis
21 One tool head rotation
axis and
One table rotation axis
1
st
rotary axis is tool head
rotation axis, and 2
nd
rotary axis
is table rotation axis.
Note
A hypothetical axis is counted as a controlled axes too.
About a hypothetical axis:
It might be convenient when assuming that there are axes fixed at a certain
angle. For instance, it is a case where the tool has inclined through the
attachment. For this case, axes assumed to be existence are hypothetical axes.
Whether each rotation axis are "Usual axes" or they are "Hypothetical axis" is
set by parameter No.19696#0 and #1.
1
st
rotary axis (master)
2
nd
rotary axis (slave)
1
st
rotary axis (master)
2
nd
rotary axis (slave)
Tool rotary axis
Table rotary axis
(4)
(4)
