FANUC Series 16i /18i Additional Manual Page 152

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
152/190
19666 Tool holder offset
[Data type] 2-word
[Unit of data]
Increment system IS-B IS-C Unit
Millimeter
machine
0.001 0.0001 Mm
Inch machine 0.0001 0.00001 Inch
[Valid data range] -99999999 to 99999999
Set the amount of the offset in a machine peculiar part from the rotation center
of the rotary axis to the tool hold position (amount of the tool holder offset).
Note
Please set this parameter by the radius value.
#7 #6 #5 #4 #3 #2 #1 #0
19608 N49 N43 NHC
[Data type] Bit
NHC Used tool offset number in tool center point control (G43.4) is :
0: The number which commanded by of H code is used.
1: The number which is specified by parameter No.19718 is used.
Note
It becomes an alarm (P/S No.009) if H code is commanded by tool center point
control (G43.4) when this parameter is ‘1’.
N43 Tool length compensation (G43/G44) in AI HPCC / AI NANO HPCC mode is:
0: Available.
1: Not available. (P/S010 alarm will be generated.)
N49 G49 command in AI HPCC / AI NANO HPCC mode is :
0: Available.
1: Not available. (P/S010 alarm will be generated.)
Note
This parameter is effective with the CCT of parameter No.19609#1 is set ‘1’.
