FANUC Series 16i /18i Additional Manual Page 144

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
144/190
3.8 Scaling and Coordinate System Rotation
#7 #6 #5 #4 #3 #2 #1 #0
8485 G51
[Data type] Bit
G51 In AI HPCC / AI NANO HPCC mode, scaling and coordinate system rotation are:
0: Disabled.
1: Enabled.
#7 #6 #5 #4 #3 #2 #1 #0
5400 SCR XSC RIN
[Data type] Bit
RIN Coordinate rotation angle command (R)
0: Specified by an absolute method
1: Specified by G90 or G91
XSC Type of scaling magnification is :
0: All axis common command. (The scaling magnification is specified by P.)
1: Each axis command. (The scaling magnification is specified by I, J, and K.)
SCR Scaling magnification unit
0: 0.00001 times (1/100,000)
1: 0.001 times
#7 #6 #5 #4 #3 #2 #1 #0
5401 SCLx
[Data type] Bit
SCLx Scaling for every axis
0: Invalidated
1: Validated
5410
Angular displacement used when no angular displacement is specified for
coordinate system rotation
[Data type] 2-word
[Unit of data] 0.001
°
[Valid data range] -360000 to 360000
This parameter sets the angular displacement for coordinate system rotation.
When the angular displacement for coordinate system rotation is not specified
with address R in the block where G68 is specified, the setting of this parameter
is used as the angular displacement for coordinate system rotation.
