#7 #6 #5 #4 #3 #2 #1 #0
19609 CCT
[Data type] Bit
CCT Cancel command of G code of 08th group is :
0: Only G49 command.
1: G49 and G49.1 are available.
Note
When this parameter is set, the power must be turned off before operation is
continued.
19718 Tool offset number of tool center point control (G43.4).
[Data type] Word
[Valid data range] 1 to 999
Set the tool offset number of the tool center point control function.
Note
This parameter is effective when the NHC of parameter No.19608#0 is ‘1’.
3.10 Tool Radius Compensation for 5-axis Machining
• Parameters related to tool rotation axes
19610 Linear axis 1 used to execute tool radius compensation for 5-axis machining
(first set)
19611 Linear axis 1 used to execute tool radius compensation for 5-axis machining
(first set)
19612 Linear axis 2 used to execute tool radius compensation for 5-axis machining
(first set)
19613 Linear axis 3 used to execute tool radius compensation for 5-axis machining
(first set)
[Data type] Byte
[Valid data range] 0 to number of controlled axes
Set the rotation axis and the linear axes used to execute tool radius
compensation for 5-axis machining (first set).
19614 Angle of rotation axis used to execute tool radius compensation for 5-axis
machining (first set)
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 - +99999999
Set the angle of the rotation axis used to execute tool radius compensation for
5-axis machining (first set).
