FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
37/190
Coordinate system rotation and scaling
Note
G50.1 and G51.1 must be specified in the G68 or G51 mode.
(Example of an incorrect program (1))
G68 … ;
G51.1…;
G50.1 …;
G69 ;
(Example of an incorrect program (2))
G51.1…;
G68…;
G50.1…;
G69 ;
(Example of a correct program)
G51.1…;
G68…;
G69 ;
G50.1…;
Other notes
Please refer to notes in clause 2.15.4.
………
