FANUC Series 16i /18i Additional Manual Page 169

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
169/190
19511
Lower feedrate limit for the deceleration function based on the acceleration of
AI HPCC / AI NANO HPCC
[Data type] 2-word
[Unit of data, Valid data range]
Valid data range
Increment system Unit of data
IS-B IS-C
Millimeter machine 1 mm/min
10
∼240000 1∼100000
Inch machine 0.1 inch/min
10
∼96000 1∼48000
Rotation axis 1 deg/min
10
∼240000 1∼100000
The deceleration function based on the acceleration of AI HPCC / AI NANO
HPCC automatically calculates the optimum feedrate according to the geometry.
Depending on the geometry, the calculated feedrate may become very low.
If this occurs, to prevent the feedrate from becoming too low, deceleration to a
feedrate below that specified for this parameter can be suppressed.
If, however, the override by the deceleration function based on the cutting load is
enabled, the feedrate may become lower than the lower feedrate limit.
