FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
140/190
3.4 Cutter Compensation C
#7 #6 #5 #4 #3 #2 #1 #0
5000 SBK
[Data type] Bit
SBK An internally created block for the cutter compensation C in AI HPCC / AI
NANO HPCC mode:
0: Does not cause a single block stop.
1: Cause a single block stop.
#7 #6 #5 #4 #3 #2 #1 #0
5003 BCK ICK SUV SUP
[Data type] Bit
SUP Start-up and cancellation of cutter compensation C and Tool Radius
Compensation for 5-axis Machining is :
0: Type A
1: Type B
SUV Start-up and cancellation of cutter compensation C and Tool Radius
Compensation for 5-axis Machining is :
0: Type A or Type B. (Conforms to parameter SUP)
1: To the movement of the next block for the vertical direction
ICK In AI HPCC / AI NANO HPCC mode, when the interference check of the cutter
compensation C is:
0: Done
1: Not done
BCK In AI HPCC / AI NANO HPCC mode, when the interference check of the cutter
compensation C determines that the programmed move direction differs from
the offset move direction by between 90 and 270 degrees:
0: An alarm occurs.
1: No alarm occurs.
