3.7.1 ARRAY_MOVE_(type)

Function

When EN is set to ON and is receiving the power flow, ARRAY_MOVE

moves, from the location specified with parameters SR and SNX (SR +

SNX - 1) to the location specified with parameters DS and DNX (DS +

DNX - 1), the number of array elements specified with input parameter

ARRAY_MOVE_(type) instructions

Name Explanation

ARRAY_MOVE_BOOL Movement of BOOL data array

ARRAY_MOVE_BYTE Movement of BYTE data array

ARRAY_MOVE_WORD Movement of WORD data array

ARRAY_MOVE_DWORD Movement of DWORD data array

ARRAY_MOVE_INT Movement of INT data array

ARRAY_MOVE_UINT Movement of UINT data array

ARRAY_MOVE_DINT Movement of DINT data array

Format

ARRAY

MOVE

(type)

SNX

DNX

(EN) (ENO)

??????? ???????

???????

N???????

LEN

Parameters

Parameter Data type Meaning

EN BOOL Execution of transmission

LEN constant

The length of each memory block

(source and destination); the

number of registers in each

memory block. 1<=LEN<=32767.
