4.8.2 BCDx_TO_(type)(x=4,8)

4.8.2.1 BCD4_TO_INT(operand)

accumulator converted value

Convert a binary coded decimal value to a single-precision integer value and store the result in the integer accumulator.

Operand: WORD variable; the BCD value for conversion.

4.8.2.2 BCD4_TO_UINT(operand)

accumulator converted value

Convert a binary coded decimal value to a single-precision unsigned integer value and store the result in the integer

accumulator.

Operand: WORD variable; the BCD value for conversion.

4.8.2.3 BCD8_TO_DINT(operand)

accumulator converted value

Convert a binary coded decimal value to a double-precision integer value and store the result in the integer

accumulator.

Operand: DWORD variable; the BCD value for conversion.

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
