3.4.1 EQ_(type)/NE_(type)
Function
When EN is set to ON and is receiving the power flow, the signs of input
parameters IN1 and IN2 are checked for equivalence (IN1 = IN2?) or
non-equivalence (IN1≠≠IN2?). When the result of the comparison is
true, power is allowed to flow and Q is set to ON.
IN1 and IN2 must both be of the same data type.
EQ_(type)/NE_(type) instructions
Name Explanation
EQ_BYTE Equal to BYTE data
EQ_WORD Equal to WORD data
EQ_DWORD Equal to DWORD data
EQ_INT Equal to INT data
EQ_UINT Equal to UINT data
EQ_DINT Equal to DINT data
NE_BYTE Not equal to DINT data
NE_WORD Not equal to WORD data
NE_DWORD Not equal to DWORD data
NE_INT Not equal to INT data
NE_UINT Not equal to UINT data
NE_DINT Not equal DINT data
Format
EQ
(type)
IN1 Q
IN2
???????
???????
???????
(EN)
NE
