3.3 Math Operations

Math operation functions

Instruction Function Parameters Data type Controlled I/O

ADD_(type) Addition IN1, IN2, Q ANY_INT EN, ENO

SUB_(type) Subtraction IN1, IN2, Q ANY_INT EN, ENO

MUL_(type) Multiplication IN1, IN2, Q ANY_INT EN, ENO

DIV_(type) Division IN1, IN2, Q ANY_INT EN, ENO

MOD_(type) Mode IN1, IN2, Q ANY_INT EN, ENO

ABS_(type) Absolute value IN, Q INT, DINT EN, ENO

SQRT_(type) Square root IN, Q ANY_INT EN, ENO
