4.4.7 Range

4.4.7.1 RANGE_INT(l1, l2, in)

If l1 < in < l2, boolean accumulator 1

Otherwise, boolean accumulator 0

Test if a value is within a range limited by two other values.

l1: INT variable or constant; the lower limit of the range.

l2: INT variable or constant; the upper limit of the range.

in: INT variable or constant; the value under test

4.4.7.2 RANGE_UINT(l1, l2, in)

If l1 < in < l2, boolean accumulator 1

Otherwise, boolean accumulator 0

Test if a value is within a range limited by two other values.

l1: UINT variable or constant; the lower limit of the range.

l2: UINT variable or constant; the upper limit of the range.

in: UINT variable or constant; the value under test.

4.4.7.3 RANGE_DINT(l1, l2, in)

If l1 < in < l2, boolean accumulator 1

Otherwise, boolean accumulator 0

Test if a value is within a range limited by two other values.

l1: DINT variable or constant; the lower limit of the range.

l2: DINT variable or constant; the upper limit of the range.

in: DINT variable or constant; the value under test.

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
