4.5.2 Logical OR

4.5.2.1 OR_BYTE(in1, in2)

accumulator in1 OR in2

Perform a logical OR between the bits of in1 and in2 and store the result in the integer accumulator.

Operands: Both in1 and in2 can be either BYTE variables or constants.

4.5.2.2 OR_WORD(in1, in2)

accumulator in1 OR in2

Perform a logical OR between the bits of in1 and in2 and store the result in the integer accumulator.

Operands: Both in1 and in2 can be either WORD variables or constants.

4.5.2.3 OR_DWORD(in1, in2)

accumulator in1 OR in2

Perform a logical OR between the bits of in1 and in2 and store the result in the integer accumulator.

Operands: Both in1 and in2 can be either DWORD variables or constants.

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
