Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 170

Additional Manual
FANUC PMC-MODEL SD7
Programming Manual
01 01.11.26
Hanaoka
New
A-78550E
EDIT DATE DESIG.
DESCRIPTION
169/
316
TITLE
DRAW.NO.
4.4.5 Less Than
4.4.5.1 LT_INT(in1, in2)
If in1 < in2, boolean accumulator 1
If in1 in2, boolean accumulator 0
Compare two single-precision integers and set the boolean accumulator to 1 if in1 is numerically less than in2.
Otherwise, clear the boolean accumulator to 0. The accumulator type is set to boolean.
in1: INT variable or constant
in2: INT variable or constant
4.4.5.2 LT_UINT(in1, in2)
If in1 < in2, boolean accumulator 1
If in1 in2, boolean accumulator 0
Compare two single-precision unsigned integers and set the boolean accumulator to 1 if in1 is numerically less than
in2. Otherwise, clear the boolean accumulator to 0. The accumulator type is set to boolean.
in1: UINT variable or constant
in2: UINT variable or constant
4.4.5.3 LT_DINT(in1, in2)
If in1 < in2, boolean accumulator 1
If in1 in2, boolean accumulator 0
Compare two double-precision integers and set the boolean accumulator to 1 if in1 is numerically less than in2.
Otherwise, clear the boolean accumulator to 0. The accumulator type is set to boolean.
in1: DINT variable or constant
in2: DINT variable or constant
For more details, see LD Functions.
Note: IL and LD functions are generally the same, with some differences in data types for operands.
