FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

214/

316

TITLE

DRAW.NO.

4.9.8 Check Even Parity

4.9.8.1 PMC_EVPAR_BYTE(in1)

accumulator Result of check

Check the even parity of BYTE data.

in1: BYTE variable or constant

4.9.8.2 PMC_EVPAR_WORD(in1)

accumulator Result of check

Check the even parity of WORD data.

in1: WORD variable or constant

4.9.8.3 PMC_EVPAR_DWORD(in1)

accumulator Result of check

Check the even parity of DWORD data.

in1: DWORD variable or constant

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
