4.4.6 Less or Equal

4.4.6.1 LE_INT(in1, in2)

If in1 in2, boolean accumulator 1

If in1 > in2, boolean accumulator 0

Compare the content of two single-precision integers and set the boolean accumulator to 1 if in1 is numerically less

than or equal to in2. Otherwise, clear the boolean accumulator to 0. The accumulator type is set to boolean.

in1: INT variable or constant

in2: INT variable or constant

4.4.6.2 LE_UINT(in1, in2)

If in1 in2, boolean accumulator 1

If in1 > in2, boolean accumulator 0

Compare the content of two single-precision unsigned integers and set the boolean accumulator to 1 if in1 is

numerically less than or equal to in2. Otherwise, clear the boolean accumulator to 0. The accumulator type is set to

boolean.

in1: UINT variable or constant

in2: UINT variable or constant

4.4.6.3 LE_DINT(in1, in2)

If in1 in2, boolean accumulator 1

If in1 > in2, boolean accumulator 0

Compare the content of two double-precision integers and set the boolean accumulator to 1 if in1 is numerically less

than or equal to in2. Otherwise, clear the boolean accumulator to 0. The accumulator type is set to boolean.

in1: DINT variable or constant

in2: DINT variable or constant

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
