3 LD INSTRUCTION GROUP

The following explains the Ladder Diagram(LD) instructions used by a

PMC sequence program.

PMC Instruction Set

Number

Class Instruction

1. Contact, Coil

--| |--, --|/|--, |+|---

--( ), --(/), --(S), --(R),--(+)

2. Timer, counter ONDTR_, TMR_, OFDT_, UPCTR_, DNCTR_

3. Math operation ADD_, SUB_, MUL_, DIV_, MOD_, ABS_, SQRT_

4. Relational EQ_, NE_, GT_, GE_, LT_, LE_, RANGE_

5. Bit operation AND_, OR_, XOR_, NOT_, SHIFTL_, SHIFTR_,

ROL_, ROR_, BIT_TEST_, BIT_SET_, BIT_CLR_,

BIT_POS_, BIT_SEQ, MASK_COMP_

6. Data move MOVE_, SWAP_, BLK_CLR_,SHFR_

7. Data table function

ARRAY_MOV_, SEARCH_EQ_, SEARCH_NE_,

SEARCH_GT_, SEARCH_GE_, SEARCH_LT_,

SEARCH_LE_

8. Conversion _TO_BCD4, _TO_BCD8, BCD4_TO_, BCD8_TO_,

_TO_INT, _TO_UINT,_TO_DINT,

9. Program flow

CALL, END, MCR/ENDMCR, MCRN, ENDMCRN,

JUMPN, LABELN, COMMENT

10. PMC operation PMC_ADD_BCD2, PMC_ADD_BCD4,PMC_ADD_BCD8,

PMC_SUB_BCD2, PMC_SUB_BCD4, PMC_SUB_BCD8,

PMC_MUL_BCD2,PMC_MUL_BCD4,PMC_MUL_BCD8,

PMC_DIV_BCD2, PMC_DIV_BCD4, PMC_DIV_BCD8,

PMC_MOD_BCD2,PMC_MOD_BCD4,PMC_MOD_BCD8,

R_TRIG, F_TRIG, PMC_DECODE_,

PMC_EVPAR_, PMC_ODPAR_, PMC_WINDOW,

PMC_EXIN, PMC_AXCTL
