FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

296/

316

TITLE

DRAW.NO.

“KIND OF DATA”

Explanation of options

PROGRAM: Outputs sequence program.

PARAMETER: Outputs PMC parameters.

- FILE NO.

“FILE NO.” is displayed only when “READ”, “COMPARE”, or

“DELETE” is selected for “FUNCTION”.

Enter the file number in the edit box.

- FILE NANE

“FILE NAME” is displayed when “WRITE”, “READ”, “COMPARE”, or

“DELETE” is selected for “FUNCTION”.

Enter the file name in the edit box.

When “READ”, “COMPARE”, or “DELETE” is selected for

“FUNCTION”, the file name corresponding to the file number entered in

“FILE NO.” is displayed automatically.

When you output to or input from a floppy disk formatted in DOS format,

the file name must be in MS-DOS format: a file name of up to eight

characters followed by an extension of up to three characters.

When you output to or input from floppy disk formatted in FANUC format,

a file name of up to 17 characters will be input.

When “WRITE” is selected for “FUNCTION” and the file name is not

entered, the following names are automatically assumed.

DATA KIND File name

LADDER PMCSD7.LAD

PARAM PMCSD7.PRM

CAUTION

1 When both “FILE NO.” and “FILE NAME” are displayed at the same time, and a value is

entered for “FILE NO.” and another file name is entered in “FILE NAME”, the value entered

in “FILE NO.” is erased and the file name entered in “FILE NAME” becomes effective.

1 Specifying the same name as that of an existing file results in an error.
