FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

163/

316

TITLE

DRAW.NO.

4.4.1 Equal

4.4.1.1 EQ_INT(in1, in2)

If in1 = in2, boolean accumulator 1

If in1 in2, boolean accumulator 0

Compare the two single-precision integers and set the boolean accumulator if they are equal. Otherwise, clear the

boolean accumulator.

in1: INT variable or constant

in2: INT variable or constant

4.4.1.2 EQ_UINT(in1, in2)

If in1 = in2, boolean accumulator 1

If in1 in2, boolean accumulator 0

Compare the two single-precision unsigned integers and set the boolean accumulator if they are equal. Otherwise, clear

the boolean accumulator.

in1: UINT variable or constant

in2: UINT variable or constant

4.4.1.3 EQ_DINT(in1, in2)

If in1 = in2, boolean accumulator 1

If in1 in2, boolean accumulator 0

Compare two double-precision integers and set the boolean accumulator if they are equal. Otherwise, clear the boolean

accumulator.

in1: DINT variable or constant

in2: DINT variable or constant

4.4.1.4 EQ_BYTE(in1, in2)

If in1 = in2, boolean accumulator 1

If in1 in2, boolean accumulator 0

Compare two BYTE data and set the boolean accumulator if they are equal. Otherwise, clear the boolean accumulator.

in1: BYTE variable or constant

in2: BYTE variable or constant

4.4.1.5 EQ_WORD(in1, in2)

If in1 = in2, boolean accumulator 1

If in1 in2, boolean accumulator 0

Compare two WORD data and set the boolean accumulator if they are equal. Otherwise, clear the boolean
