5.4.4.4 EXAMPLE FOR SETTING PARAMETERS

1) If you want to prohibit completely operator from accessing the sequence

program;

PROGRAMMER ENABLE (%SK2) ”NO”

HIDE PMC PROGRAM (%SK1) ”YES”

EDIT ENABLE (%SK15) ”NO”

ALLOW PMC STOP (%SK19) ”NO”

2) If you want to allow operator only monitoring the sequence program;

PROGRAMMER ENABLE (%SK2) ”NO”

HIDE PMC PROGRAM (%SK1) ”NO”

EDIT ENABLE (%SK15) ”NO”

ALLOW PMC STOP (%SK19) ”NO”

3) If you want to allow operator monitoring and editing the sequence

program;

PROGRAMMER ENABLE (%SK2) ”NO”

HIDE PMC PROGRAM (%SK1) ”NO”

EDIT ENABLE (%SK15) ”YES”

ALLOW PMC STOP (%SK19) ”NO”

4) If you want to allow operator monitoring and editing the sequence

program which requires stop of ladder;

PROGRAMMER ENABLE (%SK2) ”NO”

HIDE PMC PROGRAM (%SK1) ”NO”

EDIT ENABLE (%SK15) ”YES”

ALLOW PMC STOP (%SK19) ”YES”

WARNING

If a sequence program is stopped while the machine is operating, the machine

may behave unexpectedly. Before stopping the sequence program, make sure

that nobody is near the machine and that the tool cannot interfere with the

work–piece or machine. Incorrect operation of the machine presents an

extreme risk of death or serious injury to the user. Damage the tool, work–

piece, and/or the machine is also likely.
