In case of inputting discrete bit addresses, any bit address can be inputted.

Moreover, when you input byte address, all bits of the address (bit0-bit7) are

set automatically.

Maximum 32 points of signal address can be inputted. Increasing the

number of the signal address changes the capacity of “SAMPLING TIME”

or “SAMPLING FRAME” in page1. If the capacity is changed, the warning

message is displayed

Example of warning message:

In case of “TIME CYCLE” mode

“SAMPLING TIME IS REDUCED TO n SEC.”

In case of “SIGNAL TRANSITION” mode

“SAMPLING FRAME IS REDUCED TO n COUNT.”

The “n” means the maximum value that is able to input.

Explanation of the soft keys:

DELETE Clears the value of the edit box on the cursor.

SYMBOL Changes the address display to the symbol display. However,

display of the address that is not defined the symbol does not

change. This soft key also changes to “ADDRESS”. The

following soft keys are displayed.

MV.UP Exchanges the signal indicated the cursor for the signal

above one line.

MV.DWN Exchanges the signal indicated the cursor for the signal

below one line.

DELALL Clears all of the value of the edit box.

ADDRESS Changes the symbol display into the address display and

changes the soft key to “SYMBOL”.

NOTE

In the string of the symbol that can be displayed, there is a limitation

of maximum 10 characters.

The SYMBOL name is displayed only in case of the bit symbol.
