B.2 PMC system alarm messages

Alarm number Faulty location/corrective action Contents

PC004 CPU ERR xxxxxxxx:yyyyyyyy

PC006 CPU ERR xxxxxxxx:yyyyyyyy

PC009 CPU ERR xxxxxxxx:yyyyyyyy

PC010 CPU ERR xxxxxxxx:yyyyyyyy

PC012 CPU ERR xxxxxxxx:yyyyyyyy

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

A CPU error occurred in the PMC.

xxxxxxxx and yyyyyyyyy are internal error

codes.

PC030 RAM PARITY aa:bb 1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.) and

the above internal error codes.

A RAM parity error occurred in the PMC.

aa and bb are internal error codes.

PC050 NMI SLC aa:bb

PC050 I/O LINK(CH1) aa:bb aa:bb

PC050 IOLINK CH1 aaaa-

bbbb:cccc

1) Check that the I/O allocation

data matches the actual I/O

device connection.

2) Check that the cable is

connected properly.

3) Check the cable specifications.

4) Replace the I/O device interface

module, cable, master printed

circuit board, etc.

A communication error occurred in the I/O

LINK.

aa, bb and cc are internal error codes.

If this alarm is generated, probable causes

include the following:

1) Although the base expansion is assigned

when the I/O Unit A is used, the base is

not connected.

2) A cable is not connected securely.

3) Cabling is faulty.

4) I/O equipment (I/O unit, Power Mate, etc.)

is faulty.

5) Power failure of Master or Slave device

on I/O Link

6) Short circuit of DO terminal on I/O device

7) The motherboard is faulty.

PC060 FBUS xxxxxxxx:yyyyyyyy

PC061 FL-R xxxxxxxx:yyyyyyyy

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

A bus error occurred in the PMC.

PC070 SUB65 CALL (STACK) Check the correspondence between

the CALL/CALLU and SPE

instructions.

A stack error occurred in Ladder function

instruction CALL/CALLU.
