Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 156

Additional Manual
FANUC PMC-MODEL SD7
Programming Manual
01 01.11.26
Hanaoka
New
A-78550E
EDIT DATE DESIG.
DESCRIPTION
155/
316
TITLE
DRAW.NO.
4.3.1 Add
4.3.1.1 ADD_INT(in1, in2)
accumulator in1 + in2
Add two single-precision integers and store the sum in the integer accumulator.
in1: INT variable or constant
in2: INT variable or constant
4.3.1.2 ADD_UINT(in1, in2)
accumulator in1 + in2
Add two single-precision unsigned integers and store the sum in the integer accumulator.
in1: UINT variable or constant
in2: UINT variable or constant
4.3.1.3 ADD_DINT(in1, in2)
accumulator in1 + in2
Add two double-precision integers and store the sum in the integer accumulator.
in1: DINT variable or constant
in2: DINT variable or constant
For more details, see LD Functions.
Note: IL and LD functions are generally the same, with some differences in data types for operands.
