3.5.3 NOT_(type)
Function
When EN is set to ON and is receiving the power flow, NOT logically
inverts each bit of a bit string in input parameter IN. The result is
output to the corresponding bit of output parameter Q.
IN and Q must both be of the same data type.
NOT_(type) instructions
Name Explanation
NOT_BYTE Logical NOT of BYTE data
NOT_WORD Logical NOT of WORD data
NOT_DWORD Logical NOT of DWORD data
Format
NOT
(type)
IN Q
(EN) (ENO)
??????? ???????
Parameter
Parameter Data type Meaning
EN BOOL Execution of logical operation
IN BYTE, WORD, DWORD Input data
ENO BOOL Returns the value of EN
Q BYTE, WORD, DWORD Result of operation
Memory Type
Memory
Flow %I* %Q* %M* %S* %R
Constant
Omissible
EN o o o o o
IN o o o o o o
ENO o o o Note o
Q o o Note o
Note Only %SK can be specified.
