3.8.3 (type)_TO_INT

Function

When EN is set to ON and is receiving the power flow, (type)_TO_INT

converts the data of input parameter IN to INT data and outputs the

result to output parameter Q.

If the conversion results in an overflow, the maximum value for that

data type is output to Q. In such a case, ENO is not output.

Furthermore, if the conversion results in an underflow, the minimum

value for that type is output to Q. Again, in such a case, ENO is not

output.

(type)_TO_INT instructions

Name Explanation

UINT_TO_INT Converts from UINT to INT

DINT_TO_INT Converts from DINT to INT

Format

(type)

INT

IN Q

(EN) (ENO)

??????? ???????

Parameters

Parameter Data type Meaning

EN BOOL Execution of conversion

IN UINT, DINT Input data

ENO BOOL Normal end flag

Q INT Result of conversion
