FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

265/

316

TITLE

DRAW.NO.

- DATA REGISTER TABLE CONTROL SCREEN (%SK8)

YES (0): Displays PMC parameter data register table control screen.

NO (1): Does not displays PMC parameter data register table control

screen.

- HIDE PMC PARAMETER (%SK23)

NO (0): Allows PMC parameter display.

YES (1): Prevents PMC parameter display.

- PROTECT PMC PARAMETER (%SK24)

NO (0): The PMC parameter can be changed.

YES (1): The PMC parameter cannot be changed.

- HIDE PMC PROGARAM (%SK1)

NO (0): Allows the edit (output) operation of the sequence program.

YES (1): Prevents the edit (output) operation of the sequence program.

- LADDER START (%SK3)

AUTO (0): Executes the sequence program automatically after

the power turns on.

MANUAL (1): Executes the sequence program by [RUN] soft key.

- ALLOW PMC STOP (%SK19)

NO (0): Prevents run/stop operation of the sequence program.

YES (1): Allows run/stop operation of the sequence program.

NOTE

This setting effects some PMC functions.

Please refer to "5.4.4.3 Programmer protection function"

NOTE

This setting effects some PMC functions.

Please refer to "5.4.4.3 Programmer protection function"

NOTE

This setting effects some PMC functions.

Please refer to "5.4.4.3 Programmer protection function"

NOTE

This setting effects some PMC functions.

Please refer to "5.4.4.3 Programmer protection function"
