14. CUSTOM MACRO

151

Procedure for displaying variable values

1 Press the

OFFSET

SETTING

key to display the tool compensation screen.

2 Press the continuous menu key

3 Press the soft key

[MACRO] to display the macro variable screen.

4 Enter a variable number, then press soft key

[NO.SRH].

The cursor moves to the position of the entered number.

VARIABLE O1234 N12345

NO. DATA NO. DATA

100 123.456 108

101 0.000 109

102 110

103 ******** 111

104 112

105 113

106 114

107 115

ACTUAL POSITION (RELATIVE)

U 0.000 W 0.000

MEM **** *** *** 18:42:15

[ MACRO ] [ ] [ OPR ] [ ] [ (OPRT) ]

⋅ When the value of a variable is blank, the variable is null.

⋅ The mark ******** indicates an overflow (when the absolute

value of a variable is greater than 99999999) or an underflow (when

the absolute value of a variable is less than 0.0000001).

Program numbers, sequence numbers, and optional block skip numbers

cannot be referenced using variables.

Example:

Variables cannot be used in the following ways:

O#1;

/#2G00X100.0;

N#3Z200.0;

D Displaying variable

values

Procedure

Limitations
