FANUC POWER MATE 0 Operators manual Page 422

Operators manual
APPENDIX
B–63444EN/01
H. LIST OF OPERATION
413
Classifi-
cation
Operation
Function
key
Mode
SETTING
PWE = 1
KEY
SW
Function
Search Program number
search
EDIT/
MEMORY
PRGRM
O → Program number → ↓
Sequence number
search
MEMORY PRGRM After program number search; N →
Sequence number →
↓
Address word search EDIT PRGRM
Word to be searched for →
↓
Search address only EDIT PRGRM
Address to be searched for →
↓
Parameter search __ DGNOS
/PARAM
PARAM screen → → Number
→
No.
INPUT
PMC parameter
search
__ DGNOS
/PARAM
DGNOS screen →
→ Number →
PMC address
INPUT
Pitch error correction
data search
__ DGNOS
/PARAM
Pitch error correction data screen →
No. → Data number →
INPUT
Offset data search __ VAR
Offset screen → → Data number →
No.
INPUT
Macro variable data
search
__ VAR
Macro variable screen → →
Data number →
No.
INPUT
Diagnosis search __ DGNOS
/PARAM
DGNOS screen → → Number→
No.
INPUT
Editing All program delete f EDIT PRGRM
→ –9999 →
O DELETE
One program delete f EDIT PRGRM
→ Program number →O DELETE
Multiple block delete f EDIT PRGRM
→ Sequence number →
N DELETE
One block delete f EDIT PRGRM
EOB →
DELETE
Word delete f EDIT PRGRM Search for word to be deleted
→
DELETE
Word change f EDIT PRGRM After searching for word to be deleted; New
data →
ALTER
Word insertion f EDIT PRGRM After searching for word after which word is
to be inserted; New data →
INSERT
Collation Program collation EDIT PRGRM
READ
Registra-
tion from
external
Parameter input f EDIT or
emergency
stop
DGNOS
/PARAM
PARAM screen →
READ
I/O
Program input f EDIT PRGRM
READ
Pitch error correction
data input
f EDIT DGNOS/
PARAM
Pitch error correction data screen →
READ
Offset data input f EDIT VAR
Offset data screen → READ
Macro variable data
input
f EDIT PRGRM
→ Mode AUTO →
Execute the loaded program.
READ
Previous page
Next page
