FANUC POWER MATE 0 Operators manual Page 475

Operators manual

Page of 492

/ 492

FANUC Power Mate 0 Operator’s Manual

ADDITION OF FUNCTIONS TO SIMPLIFY

PROGRAMMING

B-63444EN/01-3

26 / 28

EDIT

DATE DESIG. DESCRIPTION

TITLE

DRAW.NO.

CUST.

SHEET

011129 New design

NOTE

1. The meanings of the data specified by address P, Q, and R

determined by the presence of X (U) and X (W).

2. The cycle machining is performed by G76 command with X (U)

and Z (W) specification. By using this cycle , one edge cutting is

performed and the load on the tool tip is reduced.

Making the cutting depth ∆d for the first path, and ∆d√¯n for the

nth path, cutting amount per one cycle is held constant. Four

symmetrical patterns are considered corresponding to the sign

of each address. The internal thread cutting is available. In the

above figure, the feed rate between C and D is specified by

address F, and in the other path, at rapid traverse. The sign of

incremental dimensions for the above figure is as follows:

U, W : minus (determined by the direction of the tool path AC

and CD.)

R : minus (determined by the direction of the tool path AC.)

P : plus (always)

Q : plus (always)

3. Notes on thread cutting are the same as those on G32 thread

cutting and G92 thread cutting cycle.

4. The designation of chamfering is also effective for G92 thread

cutting cycle.
