FANUC POWER MATE 0 Operators manual Page 323

Operators manual

Page of 492

/ 492

OPERATION

B–63444EN/01

9. EDITING PROGRAMS

311

6 Press the CURSOR<±> key.

7 Upon completion of search operation, the sequence number searched

for is displayed in the DPL screen.

Those blocks that are skipped do not affect the controller. This means that

the data in the skipped blocks such as coordinates and M, S and T codes

does not alter the controller coordinates and modal values.

So, in the first block where execution is to be started or restarted by using

a sequence number search command, be sure to enter required M code and

coordinates. A block searched for by sequence number search usually

represents a point of shifting from one process to another. When a block

in the middle of a process must be searched for to restart execution at the

block, specify M S, and T codes, G codes, coordinates, and so forth as

required from the MDI after closely checking the machine tool and status

of the controller at that point.

During search operation, the following checks are made:

⋅Optional block skip

⋅P/S alarm (No. 003 to 010)

During sequence number search operation, M98Pxxxx (subprogram call)

is not executed. So an alarm (No.060) is raised if an attempt is made to

search for a sequence number in a subprogram called by the program

currently selected.

O1234

M98 P5678 ;

Main program Subprogram

O5678

N88888

M99 ;

If an attempt is made to search for N8888 in the example above, an alarm is raised.

Number Contents

60 Command sequence number was not found in the se-

quence number search.

Explanations

D Operation during search

D Checking during search

Restrictions

D Searching in

sub–program

Alarm
