EDIT

DATE DESIG. DESCRIPTION

FANUC Power Mate 0 Operator’s Manual

Addition of Tool geometry and wear offset

TITLE

DRAW.NO.

CUST.

SHEET

011129 New design

Replace the description of " 13.1.5 G28 Command When Tool Position Offset is

Applied” with the fllowing.

13.1.6

G28 Command

When Tool Position

Offset is Applied

Explanations

•

Reference position return

G28 command when tool

position offset is applied

LGT = 0 (Tool geometry compensation is based on shift of the coordinate system.)

Tool position offset

(without option)

Tool geometry

compensation

Tool wear

compensation

Block for

reference

position

return

The vector is not

reflected. The

coordinates are dis-

played as if the offset

had been temporarily

canceled.

The shift is reflected.

Coordinates shifted ac-

cording to the tool

geometry

compensation are

displayed.

The vector is not

reflected.

The coordinates are dis-

played as if the offset had

been temporarily

canceled.

Absolute

position

coordinate

display

Next block

The vector is reflected. Coordinates shifted ac-

cording to the tool

geometry

compensation are

displayed.

The vector is reflected.

LGT = 1 (Tool geometry compensation is based on tool movement.)

Tool position offset

(without option)

Tool geometry

compensation

Tool wear

compensation

Block for

reference

position

return

The vector is not

reflected.

The coordinates are dis-

played as if the offset

had been temporarily

canceled.

The vector is not

reflected.

The coordinates are

displayed as if the offset

had been temporarily

canceled.

The vector is not

reflected.

The coordinates are

displayed as if the offset

had been temporarily

canceled.

Absolute

position

coordinate

display

Next block The vector is reflected. The vector is reflected. The vector is reflected.

This section describes the following operations when tool position offset is

applied: G28 command, manual reference position return, and the

canceling of tool position offset with a T00 command.

Executing reference position return G28 command when tool position

offset is applied does not cancel the tool position offset vector.

The absolute position display is as follows, however, according to the

setting of bit 4 (LGT) of parameter No. 5002.
