FANUC POWER MATE 0 Operators manual Page 359

Operators manual

Page of 492

/ 492

OPERATION

B–63444EN/01

11. SETTING AND DISPLAYING DATA

347

Dedicated screens are provided for displaying and setting tool offset

values and tool nose radius compensation values.

Procedure for setting and displaying the tool offset value and the tool nose radius

compensation value

1 Press function key

OFFSET

SETTING

2 Press chapter selection soft key

[OFFSET] or press

OFFSET

SETTING

several

times until the tool compensation screen is displayed.

OFFSET O0001 N00000

NO. X Z. R T

001 0.000 10.000 0.000 0

002 0.000 0.000 0.000 0

003 0.000 0.000 0.000 0

004 40.000 –40.000 0.000 0

005 0.000 0.000 0.000 0

006 0.000 0.000 0.000 0

007 0.000 0.000 0.000 0

008 0.000 0.000 0.000 0

ACTUAL POSITION (RELATIVE)

U 101.000 W 202.094

> _

MDI **** *** *** 16:05:59

[ OFFSET ][ SETING ][ WORK ][ ][ (OPRT) ]

3 Move the cursor to the compensation value to be set or changed using

page keys and cursor keys, or enter the compensation number for the

compensation value to be set or changed and press soft key

[NO.SRH].

4 To set a compensation value, enter a value and press soft key

[INPUT].

To change the compensation value, enter a value to add to the current

value (a negative value to reduce the current value) and press soft key

[+INPUT]. Or, enter a new value and press soft key [INPUT].

TIP is the number of the virtual tool tip (see Programming).

A decimal point can be used when entering a compensation value.

An external input/output device can be used to input or output a cutter

compensation value. See Chapter III–8.

16 groups are provided for tool compensation.

11.4.1

Setting and Displaying

the Tool Offset Value

Explanations

D Decimal point input

D Other method

D Tool offset memory
