Setting a Workpiece Coordinate System, 66

Setting and Displaying Data, 324

Setting and Displaying the Tool Offset Value, 347

Simple Calculation of Incorrect Thread Length , 393

Simple Call (G65), 167

Single Block, 257

Skip Function (G31), 50

Soft Keys, 212

Specifying the Spindle Speed Value Directly (S5-digit

Command) , 77

Specifying the Spindle Speed with A Code, 77

Spindle Speed Function (S Function) , 76

Status when Turning Power ON, When Clear and

when Reset, 399

Stroke Check, 261

Subprogram (M98, M99), 96

Subprogram Call Using an M Code, 175

Subprogram Calls Using a T Code, 176

System Variables , 152

[T]

T Code for Tool Offset, 101

Tape Code List, 383

Test Operation, 252

Testing a Program, 196

Tool Compensation and Number of Tool CompensaĆ

tion, 146

Tool Compensation Values, Number of CompensaĆ

tion Values, and Entering Values from the Program

(G10), 146

Tool Figure and Tool Motion by Program , 29

Tool Function (T Function) , 81

Tool Movement Along Workpiece Parts Figure-InĆ

terpolation , 12

Tool Movement by Programming-automatic OperaĆ

tion, 194

Tool Movement in Offset Mode, 120

Tool Movement in Offset Mode Cancel, 132

Tool Movement in Start-up, 118

Tool Movement Range-stroke , 30

Tool Offset, 101

Tool Path at Corner, 395

Tool Selection, 82, 101

Turning on the Power, 228

[U]

Unconditional Branch (GOTO Statement), 163

[V]

Variables , 149

[W]

Warning Messages, 224

Word Search, 295

Work Position and Move Command, 110

Workpiece Coordinate System, 66
