FANUC POWER MATE 0 Operators manual Page 299

Operators manual
OPERATION
B–63444EN/01
8. DATA INPUT/OUTPUT
287
Output format is as follows:
NP ;. . . . . . .
N A1P A2P ;. . . . . . . .
NP ;. . . . . . .
N:Parameter No.
A:Axis No.(n is the number of control axis)
P:Parameter setting value .
Pitch error compensation data are loaded into the memory of the CNC
from a floppy. The input format is the same as the output format. See
Section
8.6.4. When a pitch error compensation data is loaded which has
the corresponding data number as a pitch error compensation data already
registered in the memory, the loaded data replaces the existing data.
Pitch error compensation data
1 Make sure the input device is ready for reading.
2 When using a floppy, search for the required file according to the
procedure in Section
8.2.
3 Press the EMERGENCY STOP button on the machine operator’s
panel.
4 Press function key
OFFSET
SETTING
.
5 Press the soft key
[SETING] for chapter selection.
6 Enter 1 in response to the prompt for writing parameters (PWE).
Alarm P/S100 (indicating that parameters can be written) appears.
7 Press soft key
SYSTEM
.
8 Press the rightmost soft key
(next–menu key)and press chapter
selection soft key
[PITCH].
9 Press soft key
[(OPRT)].
10 Press the rightmost soft key
(next–menu key).
11 Press soft keys
[READ] and [EXEC].
Parameters are read into memory. Upon completion of input, the
“INPUT” indicator at the lower–right corner of the screen disappears.
12 Press function key
OFFSET
SETTING
.
13 Press soft key
[SETING] for chapter selection.
14 Enter 0 in response to the prompt for writing parameters.
Explanations
D Output format
8.6.3
Inputting Pitch Error
Compensation Data
Procedure (CRT/MDI)
Previous page
Next page
