B-63445EN/01-1

4/7

EDIT

DATE DESIG. DESCRIPTION

FANUC Power Mate 0

THE FUNCTION OF ABSOLUTE PULSE CODER

MAINTENUNCE MANUAL

TITLE

DRAW.NO. CUST.

SHEET

000512 New design

Absolute position data in the serial pulse coder was lost.

[This alarm occurs if the serial pulse coder is replaced, the position

feedback signal line is removed from the serial pulse coder, the

battery or

its cable is removed, or parameters are loaded into the Power Mate

as a

batch.]

Machine position must be memorized using the following method:

If a battery alarm (306) occurs in the pulse coder, recover the

normal

battery status, rotate the motor through at least one turn, then turn

the

power off on again.

(1) Execute manual reference position return only for an axis for

which

this alarm was generated.

(2) Press RESET key at the end of reference position return to

release the

alarm.

Since the reference position is different from the former one,

change the

grid shift value (PRM 1850) to correct the position.

#7 #6 #5 #4 #3 #2 #1 #0

1815 APC APZ

#5(APCx) 0: Position detector is incremental pulse coder.

1: Position detector is absolute pulse coder.

#4(APZx) Reference position of absolute pulse coder is:

0: not established

1: established

Absolute pulse coder, cable, or base PCB is faulty.

7.12

ALARM 300

(REQUEST FOR

REFERENCE

POSITION RETURN)

Remedies

! When serial pulse

coder is changed

Related parameters

7.13

ALARM 301 TO 305

(ABSOLUTE PULSE

CODER FAULTY

)
