APPENDIXC. RANGE OF COMMAND VALUE

B–63444EN/01

388

Increment system

IS–B

Least input increment 0.0001 inch

Least command increment X : 0.00005 inch

Y : 0.0001 inch

Max. programmable dimension ±9999.9999 inch

Max. rapid traverse *1 9600 inch/min

Feedrate range *1 Feed per minute : 0.01 to 9600 inch/min

Feed per revolution 0.000001 to 9.999999 inch/rev

Incremental feed 0.0001, 0.001, 0.01, 0.1 inch/step

Tool compensation 0 to ±99.9999 inch

Backlash compensation 0 to ±0.0255 inch

Dwell time 0 to 99999.999 sec

Increment system

IS–B

Least input increment 0.001 mm

Least command increment X : 0.00005 inch

Y : 0.0001 inch

Max. programmable dimension ±99999.999 mm

Max. rapid traverse *1 9600 inch/min

Feedrate range *1 Feed per minute : 1 to 240000 mm/min

Feed per revolution 0.0001 to 500.0000 mm/rev

Incremental feed 0.001, 0.01, 0.1, 1mm/step

Tool compensation 0 to ±999.999 mm

Backlash compensation 0 to ±0.0255 inch

Dwell time 0 to 99999.999 sec
