OPERATION11. SETTING AND DISPLAYING DATA

B–63444EN/01

368

The current mode, automatic operation state, alarm state, and program

editing state are displayed on the next to last line on the CRT screen

allowing the operator to readily understand the operation condition of the

system.

If data setting or the input/output operation is incorrect, the CNC does not

accept the operation and a warning message is displayed on the next to last

line of the CRT screen. This prevents invalid data setting and input/output

errors.

EDIT STOP MTN FIN ALM hh:mm:ss

––EMG––

(7)

(1)

(2) (3) (4)

(5)

(6)

(Display soft keys)

(8) Data is out of range.

(Note) Actually, (8) is displayed in the area starting from (2).

(Note) Actually, 5 is displayed in

the area for (3) and (4).

INPUT

(8)

MDI : Manual data input

MEM : Automatic operation

EDIT : Memory editing

JOG : Jog feed

STEP : Manual incremental feed

REF : Manual reference position return

**** : Reset (When the power is turned on or the state in which

program execution has terminated and automatic operation has

terminated.)

STOP : Automatic operation stop (The state in which one block has

been executed and automatic operation is stopped.)

HOLD : Feed hold (The state in which execution of one block has been

interrupted and automatic operation is stopped.)

STRT : Automatic operation start–up (The state in which the system

operates automatically)

MTN : Indicates that the axis is moving.

DWL : Indicates the dwell state.

*** : Indicates a state other than the above.

FIN : Indicates the state in which an auxiliary function is being

executed. (Waiting for the complete signal from the PMC)

*** : Indicates a state other than the above.

––EMG––

: Indicates emergency stop. (Reversed display)

–RESET– : Indicates that the reset signal is being received.

ALM

: Indicates that an alarm is issued. (Reversed display)

BAT

: Indicates that the battery is low. (Reversed display)

Space : Indicates a state other than the above.

hh:mm:ss : Hours, minutes, and seconds

11.6.2

Displaying the Status

and Warning for Data

Setting or Input/Output

Operation

Explanations

D Description of each

display (CRT/MDI)

(1) Current mode

(2) Automatic operation

status

(3) Axis moving

status/dwell status

(4) State in which an

auxiliary function is

being executed

(5) Emergency stop or

reset status

(6) Alarm status

(7) Current time
