OPERATION

B–63444EN/01

8. DATA INPUT/OUTPUT

281

A program stored in the memory of the controller unit is output to a

floppy.

Outputting a program

1 Make sure the output device is ready for output.

2 Specify the punch code system (ISO or EIA) using a parameter.

3 Press the EDIT switch on the machine operator’s panel.

4 Press function key

PROG

5 Press soft key[(OPRT)].

6 Press the rightmost soft key

(next–menu key).

7 Enter address O.

8 Enter a program number. If –9999 is entered, all programs stored in

memory are output.

To output multiple programs at one time, enter a range as follows :

O∆∆∆∆,Ojjjj

Programs No.∆∆∆∆ to No.jjjj are output.

9 Press soft keys

[PUNCH] and [EXEC]

The specified program or programs are output.

A program registered in memory can be punched using the procedure below.

1 Set the output device ready for punch operation.

2 Set a setting data punch code (ISO or EIA).

3 Select EDIT mode.

4 Press

<PRGRM> to display the program screen.

5 Key in address O.

6 Key in a desired program number.

Entering –9999 causes all programs in memory to be output.

7 The number of input program is punched with pushing

<WRITE>.

When output is conducted to the floppy, the program is output as the new

file after the files existing in the floppy. New files are to be written from

the beginning with making the old files invalid, use the above output

operation after the N0 head searching.

When P/S alarm 86 occurs during program output, the floppy is restored

to the condition before the output.

When program output is conducted after N1 to N9999 head searching, the

new file is output as the designated n–th position. In this case, 1 to n–1

files are effective, but the files after the old n–th one are deleted. If an

alarm occurs during output, only the 1 to n–1 files are restored.

8.4.2

Outputting a Program

Procedure (CRT/MDI)

Procedure (DPL/MDI)

Explanations

(Output to a floppy)

D File output location

D An alarm while a

program is output

D Outputting a program

after file heading
