FANUC POWER MATE 0 Operators manual Page 425

Operators manual
Index B–63444EN/01
i–2
Displaying the Program Number, Sequence Number,
and Status, and Warning Messages for Data Setting
or Input/Output Operation, 367
Displaying the Status and Warning for Data Setting
or Input/Output Operation, 368
DPL/MDI Panel, 208
Dry Run, 256
Dwell (G04), 59
[E]
Editing a Part Program , 198
Editing of Custom Macros, 314
Editing Programs , 293
Emergency Stop, 259
External I/O Devices, 225
External Output Commands, 181
[F]
FANUC Handy File, 227
Feed Functions , 52
Feed-feed Function , 15
Feedrate Override, 254
File Deletion, 277
File Search, 275
Files, 273
Function Keys, 211
Function Keys and Soft Keys, 210
[G]
G28 Command in Tool-tip Radius Compensation
Mode, 144
G28 Command when Tool Position Offset is Applied,
104
General Precautions for Offset Operations, 143
General Procedure for Operating Machine Equipped
with NC, 5
General Screen Operations, 210
[H]
Heading a Program , 299
Help Function , 370
How to Indicate Command Dimensions for Moving
the Tool - Absolute, Incremental Commands, 20
How to View the Position Display Change without
Running the Machine, 197
[I]
Imaginary Tool Nose, 106
Inch/Metric Conversion (G20, G21), 73
Incorrect Threaded Length , 391
Increment System, 32
Incremental Feed, 237
Input Command from MDI, 142
Inputting a Program, 278
Inputting and Outputting Parameters , 285
Inputting Custom Macro Common Variables , 290
Inputting Offset Data, 283
Inputting Parameters , 285
Inputting Pitch Error Compensation Data, 287
Inputting/Outputting Custom Macro Common VariĆ
ables, 290
Inserting a Word, 300
Inserting, Altering and Deleting a Word, 294
Interference Check, 135
Interpolation Functions , 36
[J]
Jog Feed, 233
[K]
Key Input and Input Buffer, 223
[L]
Limitations , 180
Linear Interpolation (G01), 39
List of Functions and Tape Format, 385
List of Operation, 410
[M]
Machine Coordinate System, 65
Machine Lock and Auxiliary Function Lock, 253
Macro Call, 167
