OPERATION

3.MANUAL OPERATION

B–63444EN/01

236

Parameter HPF (bit 4 of No. 7100) specifies as follows:

SET VALUE 0: The feedrate is clamped at the rapid traverse rate

andgenerated pulses exceeding the rapid traverse rate are

ignored.(The distance the tool is moved may not match

the graduations on the manual pulse generator.)

SET VALUE 1: The feedrate is clamped at the rapid traverse rate and

generated pulses exceeding the rapid traverse rate are not

ignored but accumulated in the CNC.

(No longer rotating the handle does not immediately stop

the tool. The tool is moved by the pulses accumulated

in the CNC before it stops.)

WARNING

1 Rotate the manual pulse generator at a rate of five rotations

per second or lower. If the manual pulse generator is

rotated at a rate higher than five rotations per second, the

tool may not stop immediately after the handle is no longer

rotated or the distance the tool moves may not match the

graduations on the manual pulse generator.

2 Rotating the handle quickly with a large magnification such

as x100 moves the tool too fast. The feedrate is clamped

at the rapid traverse feedrate.

Explanations

D A command to the MPG

exceeding rapid traverse

rate (HPF)
