OPERATION12. HELP FUNCTION

B–63444EN/01

372

3 To get details on another alarm number, first enter the alarm number,

then press soft key

[SELECT]. This operation is useful for

investigating alarms not currently being raised.

HELP (ALARM DETAIL) 1234 N00001

NUMBER : 100

M‘SAGE : PARAMETER WRITE ENABLE

FUNCTION :

ALARM :

<<ALARM IS NOT GENERATED>>

ENTER THE DETAIL–REQUIRED ALARM NUMBER,

AND PRESS [SELECT] KEY.

MEM

**** *** ***

SELECT

>100

Fig.12 (d) ALARM DETAIL Screen when P/S 100 is selected

10:00:00

S 0 T0000

4 To determine an operating procedure for the controller, press the soft

key

[2 OPR] key on the HELP (INITIAL MENU) screen. The

OPERATION METHOD menu screen is then displayed. (See Fig.12

(e).)

HELP (OPERATION METHOD) O1234 N00001

1. PROGRAM EDIT

2. SEARCH

3. RESET

4. DATA INPUT WITH MDI

5. DATA INPUT WITH TAPE

6. OUTPUT

7. INPUT WITH FANUC CASSETTE

8. OUTPUT WITH FANUC CASSETTE

9. MEMORY CLEAR

MEM

**** *** ***

3 PARA

(OPRT)1 ALAM

2 OPR

Fig.12 (e) OPERATION METHOD Menu Screen

10:00:00

S 0 T0000

To select an operating procedure, enter an item No. from the keyboard

then press the

[SELECT] key.

MEM

****

*** ***

SELECT

Fig.12 (f) How to select each OPERATION METHOD screen

10:00:00

S 0 T0000

OPERATION METHOD

screen
