FANUC Power Mate 0

THE FUNCTION OF ABSOLUTE PULSE CODER

MAINTENUNCE MANUAL

TITLE

DRAW.NO. CUST.

SHEET

000512 New design

#7 #6 #5 #4 #3 #2 #1 #0

Alarm 3 CSA BLA PHA RCA BZA CKA SPH

DGN(202)

CSA : The serial pulse coder is defective.

BLA : The battery voltage is low. (warning)

PHA : The serial pulse coder or feed back cable is defective.

Counting the feedback signal is in error.

RCA : The serial pulse coder is defective. Counting is in error.

If the RCA bit is set to 1 when both the FBA bit (bit 1 of

alarm 1)and ALD bit of alarm 2 are set to 1 and the EXP

bit of alarm 2 (internal hardware disconnection ) is set to

1, a count miss alarm (CMAL) occurs in the pulse coder.

BZA : battery voltage becomes 0. Replace batteries and set

the reference position.

CKA : The serial pulse coder is defective. Inter

clock has stopped.

SPH : The serial pulse coder or feedback cable is defective.

Counting the feedback signal is in error.

#7 #6 #5 #4 #3 #2 #1 #0

1815 APC APZ

APC Position transducer

0: Other than absolute position transducer

1: Absolute position transducer (absolute pulse coder)

APZ Machine position and absolute position transducer when the absolute

position transducer is used

0: Not corresponding

1: Corresponding

(Turn to 1 after establishment)

When the battery of absolute pulse coder is connected at first time

or replace the battery, first rotate the motor through at least one

turn then turn the power off, before returning to the reference

position.

Please add the following parameters in the “ 5.3 ADJUSTING REFERENCE POSITION

(DOG METHOD)”

Replace the description of " Contents " in the chapter " 7.11 ALARM 90 (REFERENCE

POSITION RETURN IS ABNORMAL)" as follows.
