PROGRAMMING

B–63444EN/01

14. CUSTOM MACRO

159

⋅ When the ROUND function is used in NC statement addresses, the

ROUND function rounds off the specified value according to the least

input increment of the address.

Example:

Creation of a drilling program that cuts according to the values

of variables #1 and #2, then returns to the original position

Suppose that the increment system is 1/1000 mm, variable #1

holds 1.2345, and variable #2 holds 2.3456. Then,

G00 G91 X–#1; Moves 1.235 mm.

G01 X–#2 F300; Moves 2.346 mm.

G00 X[#1+#2];

Since 1.2345 + 2.3456 = 3.5801, the travel distance is 3.580,

which does not return the tool to the original position.

This difference comes from whether addition is performed before

or after rounding off. G00X–[ROUND[#1]+ROUND[#2]] must be

specified to return the tool to the original position.

When the absolute value of the integer produced by an operation on a

number is greater than the absolute value of the original number, such an

operation is referred to as rounding up to an integer. Conversely, when

the absolute value of the integer produced by an operation on a number

is less than the absolute value of the original number, such an operation

is referred to as rounding down to an integer. Be particularly careful when

handling negative numbers.

Example:

Suppose that #1=1.2 and #2=–1.2.

When #3=FUP[#1] is executed, 2.0 is assigned to #3.

When #3=FIX[#1] is executed, 1.0 is assigned to #3.

When #3=FUP[#2] is executed, –2.0 is assigned to #3.

When #3=FIX[#2] is executed, –1.0 is assigned to #3.

When a function is specified in a program, the first two characters of the

function name can be used to specify the function.

Example:

ROUND → RO

FIX → FI

(1) Functions

(2) Operations such as multiplication and division (*, /, AND, MOD)

(3) Operations such as addition and subtraction (+, –, OR, XOR)

Example) #1=#2+#3*SIN[#4];

(1)

(2)

(3)

(1), (2), and (3) indicate the order of operations.

D Rounding up and down

to an integer

D Abbreviations of

arithmetic and logic

operation commands

D Priority of operations
