FANUC POWER MATE 0 Operators manual Page 398

Operators manual
APPENDIX
B–63444EN/01
C. RANGE OF COMMAND VALUE
389
Increment system
IS–B
Least input increment 0.001 deg
Least command increment ±0.001 deg
Max. programmable dimension ±99999.999 deg
Max. rapid traverse *1 240000 deg/min
Feedrate range *1 1 to 240000 deg/min
Incremental feed 0.001, 0.01, 0.1, 1deg/step
Tool compensation 0 to ±999.999 mm
Backlash compensation 0 to ±0.255 deg
NOTE
*1 The feedrate range shown above are limitations depending
on CNC interpolation capacity.
As a whole system, limitations depending on servo system
must also be considered.
Rotation axis
Previous page
Next page
