FANUC POWER MATE 0 Operators manual Page 258

Operators manual

Page of 492

/ 492

OPERATION

4. AUTOMATIC OPERATION

B–63444EN/01

246

In the MDI mode, a program consisting of up to 10 lines can be created in

the same format as normal programs and executed from the MDI panel.

MDI operation is used for simple test operations.

The following procedure is given as an example. For actual operation,

refer to the manual supplied by the machine tool builder.

Procedure for MDI Operation

1 Press the MDI mode selection switch.

2 Press the

PROG

function key on the CRT/MDI panel to select the

program screen. The following screen appears:

PROGRAM ( MDI )

MDI

* * * *

* * * * * * 20:40:05

O0010

N00002

PRGRM

CURRNT

NEXT (OPRT)

O0000

;

G00 G40 G80 G54 G69

G18 G22 G21 G99 G67

MDI

Program number O0000 is entered automatically.

3 Prepare a program to be executed by an operation similar to normal

program editing. M99 specified in the last block can return control to

the beginning of the program after operation ends. Word insertion,

modification, deletion, word search, address search, and program

search are available for programs created in the MDI mode. For

program editing, see Chapter 9.

4 To entirely erase a program created in MDI mode,use one of the

following methods:

a. Enter address

, then press the

DELETE

key on the MDI panel.

b. Alternatively, press the

RESET

key. In this case, set bit 7 of

parameter 3203 to 1 in advance.

5 To execute a program, set the cursor on the head of the program. (Start

from an intermediate point is possible.) Push Cycle Start button on

the operator’s panel. By this action, the prepared program will start.

When the program end (M02, M30) or ER(%) is executed, the

prepared program will be automatically erased and the operation will

end. By command of M99, control returns to the head of the prepared

program.

4.2

MDI OPERATION

Procedure for CRT/MDI
