OPERATION11. SETTING AND DISPLAYING DATA

B–63444EN/01

336

The actual feedrate on the machine (per minute) can be displayed on a

current position display screen or program check screen by setting bit 0

(DPF) of parameter 3105.

Display procedure for the actual feedrate on the current position display screen

1 Press function key

POS

to display a current position display screen.

MEM STRT MTN *** 09:06:35

[ WORK ] [ REL ] [ ALL ] [ HNDL ] [(OPRT)]

ACTUAL POSITION(WORK) O1000 N00010

ACT.F 3000 MM/M

S 0 T0000

X 123.456

Z 363.233

Actual feedrate is displayed after ACT.F.

The actual feedrate is displayed in units of millimeter/min or inch/min

(depending on the specified least input increment) under the display of the

current position.

The actual rate is calculated by the following expression:

Fact +

i+1

(fi)

where

n : Number of axes

fi :Cutting feed rate in the tangential direction of each axis or rapid

traverse rate

Fact : Actual feedrate displayed

The display unit:mm/min (metric input).

inch/min (Inch input, Two digits below the decimal

point are displayed.)

The feedrate along the PMC axis can be omitted by setting bit 1 (PCF) of

parameter 3105.

In the case of feed per revolution, the actual feedrate displayed is the feed

per minute rather than feed per revolution.

The program check screen also displays the actual feedrate.

11.1.4

Actual Feedrate

Display

Procedure for CRT/MDI

Explanations

D Actual feedrate value

D Actual feedrate display

of feed per revolution

D Actual feedrate display

on the other screen
